Air Compressor Suction Unit/

SC002 Electric Suction Unit

SC002 Electric Suction Unit

Voltage: 110V-220V 50Hz/60Hz
Max negative pressure: >0.09Mpa
Noise: <60dB

  • Product Detail

SC002 Electric Suction Unit

Features:

Adopting oil-free piston pump

Clean-without pollution of oil and smoke

Convent-no need add oil to maintain daily

Safe-no plus pressure during using

No engorging-keep pressure when the machine stops, so the liquid won't flow backwards

Complete plastic panels, hand-switch and foot-switch for operating easily. Select negative pressure at will with no level for pressure adjustment, and overflow protection mechanism, safe and reliable.



Ultimate negative pressure value

≥ 0.09 MPa

Power supply

AC220V±22V/110V±11V, 50Hz/60Hz ±1Hz

Input power

150VA+15%

Reservoir

≥ 2500 mL/pc, 2pcs in the suction unit

Regulating scope of negative pressure

0.02MPa ~ultimate negative pressure value

Pumping rate

≥ 20L/min

Noise

60 dB(A)

Dimension

380mm X 312mm X 480mm

Weight

16 kg

Ambient temperature

5℃ ~ 35℃

Relative humidity

≤ 80℃

Atmospheric pressure

86kPa ~ 106kPa
